12511 Precision-Engineered 1.25mm Centerline Pitch PCB Connectors for Electronics

12511‐nY‐G series

▲SPECIFICATIONS        Unit:mm

△Current rating:1A AC/DC;

△Voltage rating:250V AC/DC;

△Temperature range:-25℃ to +85℃;

△Contact resistance:20 mΩ max;

△Insulation resistance:100 MΩ min;

△Withstanding voltage:500 VAC/minute;

12511‐T series

▲SPECIFICATIONS         Unit:mm

△Current rating:1A AC/DC;

△Voltage rating:250V AC/DC;

△Temperature range:-25℃ to +85℃;

△Contact resistance:20 mΩ max;

△Insulation resistance:100 MΩ min;

△Withstanding voltage:500 VAC/minute;
